How the Estimator Works

Understand the calculation and the tables returned by polarstate.

The Aalen-Johansen estimator generalizes Kaplan-Meier reasoning to one or more absorbing outcomes. In polarstate, code 0 means that follow-up ended without an observed event, code 1 is the event of interest, and optional code 2 is a competing event.

A watercolor illustration of Aalen and Johansen presenting state-occupancy curves, surrounded by polar bears.

An illustrated introduction to the Aalen-Johansen estimator.

flowchart LR
    O["Under observation"] -->|"Code 0"| C["Right-censored"]
    O -->|"Code 1"| E["Event of interest"]
    O -.->|"Optional code 2"| R["Competing event"]
    style O fill:#dff3f8,stroke:#1f5f82
    style E fill:#e3f4ea,stroke:#287a4b
    style R fill:#f8e8ef,stroke:#9b4668

Codes 0 and 1 are sufficient for a single-event analysis. Code 2 adds a second absorbing state; it is not required by the API.

The estimator

For event type j, the estimated state-occupancy probability is

\widehat F_j(t) = \sum_{u \le t} \widehat S(u-) \frac{dN_j(u)}{Y(u)}. \tag{1}

Here, Y(u) is the risk set immediately before time u, dN_j(u) is the number of type-j events at that time, and \widehat S(u-) is the probability of remaining in state 0 immediately beforehand.

From observations to estimates

The columns returned by prepare_event_table() expose each component of Equation 1:

  1. Observations are grouped by time and counted by outcome.
  2. at_risk supplies Y(u).
  3. csh_1 and csh_2 supply dN_j(u)/Y(u).
  4. previous_overall_survival supplies \widehat S(u-).
  5. transition_probabilities_to_*_at_times contains each weighted increment.
  6. state_occupancy_probability_*_at_times cumulatively sums those increments.

Event-table columns

Column Interpretation
times Unique observed time
count_0 Observations right-censored at that time
count_1 Events of interest at that time
count_2 Competing events at that time; zero in a single-event analysis
events_at_times Total observations ending follow-up at that time
at_risk Observations still under observation immediately before that time
csh_1, csh_2 Cause-specific event increments: event count divided by risk set
conditional_survival Probability of avoiding either event at that time, conditional on being at risk
overall_survival Product of conditional-survival increments through that time
previous_overall_survival Survival immediately before the current time
transition_probabilities_to_*_at_times Probability mass entering each absorbing state at that time
state_occupancy_probability_*_at_times Cumulative probability of occupying each absorbing state

The historical trainsition_probabilities_to_*_at_times spelling remains as a backward-compatible alias. The corrected names were introduced in polarstate 0.1.8 and are the canonical names used by the implementation. New code should use the correctly spelled names and select event-table columns by name rather than position.

There is currently no scheduled release that removes the historical aliases. If they are removed, polarstate will first announce the removal version and emit a deprecation warning during a documented compatibility window; removal will be released as a breaking schema change.

From the event table to requested horizons

predict_aj_estimates() performs a backward as-of join: for each requested horizon, it returns the latest estimate available at or before that time. Horizons before the first observed event receive probability 1 for state 0 and 0 for the absorbing states.

Column Interpretation
times Requested horizon or observed event time
state_occupancy_probability_0 Probability of remaining event-free
state_occupancy_probability_1 Probability of the event of interest
state_occupancy_probability_2 Probability of the competing event
estimate_origin Whether the row came from a requested horizon or the full event table

At each horizon,

P_0(t) + P_1(t) + P_2(t) = 1.

For a single-event analysis, P_2(t)=0, so P_0(t) is the Kaplan-Meier survival estimate and P_1(t)=1-P_0(t).

Interpretation

A raw event proportion ignores how long each observation was followed. Aalen-Johansen uses the risk set at each event time, so right-censoring removes an observation from later risk sets without treating it as an event.

Important

The estimates describe the observed cohort under the usual independent censoring assumptions. They do not by themselves adjust for confounding or establish causal effects.

Compare the same estimates with other implementations in Package Comparisons, continue with Recipes for common data structures, or consult the API Reference for complete function details.
